Inicio ProductosEquipos de prueba para productos derivados del petróleo

ASTM D2420 LPG Hydrogen Sulfide Tester for Liquefied Petroleum Gas

ASTM D2420 LPG Hydrogen Sulfide Tester for Liquefied Petroleum Gas

    • ASTM D2420 LPG Hydrogen Sulfide Tester for Liquefied Petroleum Gas
    • ASTM D2420 LPG Hydrogen Sulfide Tester for Liquefied Petroleum Gas
    • ASTM D2420 LPG Hydrogen Sulfide Tester for Liquefied Petroleum Gas
  • ASTM D2420 LPG Hydrogen Sulfide Tester for Liquefied Petroleum Gas

    Datos del producto:

    Lugar de origen: PORCELANA
    Nombre de la marca: AI
    Certificación: ISO
    Número de modelo: AIC-2420

    Pago y Envío Términos:

    Cantidad de orden mínima: 1 set
    Precio: Negociable
    Detalles de empaquetado: Caja de madera contrachapada
    Tiempo de entrega: 20 días
    Condiciones de pago: Unión occidental, T/T, L/C
    Capacidad de la fuente: 20 juegos por mes
    Contactar ahora
    Descripción detallada del producto
    Estándar de prueba: ASTM D2420, SH/T0125 Modo de control de la temperatura: Termostato PID digital
    poder total: 1000W Dimensión: 440*310*600mm
    Fuente de alimentación: AC220V 50Hz Garantía: 1 año
    Color: Blanco Peso: 20 kg

    ASTM D2420 LPG Hydrogen Sulfide Tester

    Introduction
    This instrument is used to detect the presence or absence of hydrogen sulfide in liquefied petroleum gas. The lower limit of detection of hydrogen sulfide is 4mg/m3.If methyl mercaptan is present on the lead acetate test strip, it will produce a short-term yellow stain, but it will disappear completely in less than 5 minutes.Other sulfides in liquefied petroleum gas do not interfere with this test.

    I. Main features
    ◆The test glass tube meets the requirements of the standard, with a glass hook inside.
    ◆Provide 500ml stainless steel sampler.
    ◆The gas passes through the thermal evaporation bath and the needle valve adjusts the flow.
    ◆Imported Omron PID temperature controller, digital continuous display temperature, accuracy 0.1℃.



    II.Technical specifications
    Applicable Standard
    ASTM D2420, SH/T0125
    Heating mode
    Electric heating tube
    Temperature controlling mode
    Digital PID thermostat
    Flow control
    Needle valve adjustment, flow meter displays flow
    Power supply
    AC220V/ 50HZ
    Total power
    1000W
    Dimension
    440*310*600mm
    Weight
    20KG



    III.Pacakge list
    No.
    Name
    Quantity
    Unit
    1
    Main unit
    1 Set
    2
    Fuse 20A
    4
    PC
    3
    Sampling cylinder 500ml
    1
    PC
    4
    Glass hook
    1
    PC
    5
    Fuse 20A
    4
    PC
    6
    Rubber stopper 10#
    1
    PC
    7
    Glass cylinder
    1
    Set
    8
    Watch glass
    1
    PC
    9
    Glass connecting pipe
    1
    Root
    10
    Breathing pipe
    1
    PC
    11
    Test strip
    1
    Box
    12
    User manual
    1
    Copy
    ASTM D2420 LPG Hydrogen Sulfide Tester for Liquefied Petroleum Gas
