Introduction
The test principle of the ash percentage tester is to let the sample evaporation or burning under certain conditions,and put it in a strong heat source burning and ashing, then calcine the solid residue,then it can test the ash content of the test product.
The ash percentage tester is suitable for the detection of unused commodity engine coolant and liquid antirusts. It can also used to identify the type of coolants and antirusts, but it is not suitable for determining the total inhibitor content.
Characteristic
1.Integrated structure,overall small,beautiful appearance.
2.The shell is made of mould forming.
3.Ceramic fiber furnace.
4.A variety of insulation materials for insulating,ensure that the staff will not burn.
5.Microcomputer processing and PID control,digital display temperature,0.1℃, Pt100 RTD temperature probe.
Technical specifications
| 1 |
Applicable standards |
ASTM D1119 |
| 2 |
Temperature controlling range |
room temperature-900℃ |
| 3 |
Heating mode |
imported electric wire heating |
| 4 |
Temperature control mode |
Digital PID temperature controller |
| 5 |
Crucible capacity |
50mL |
| 6 |
Power supply |
AC220V/50Hz |
Photo of ASTM D1119 Ash Percent Tester For Engine Coolant and Rust Inhibitor
