ASTM D86 Fully Automatic Atmospheric Distilled Oil Analyzer
Characteristics
◆Big LCD screen,which can show distillation rate,temperature,recovery volume ratio etc.
◆Automatic optimize all parameters of heating power.
◆Feedback heater,bumping after placing sample.
◆All components are made by fire-resistant,high temperature resistant and non-toxic materials,
◆IR sensor makes sure accuracy of measuring volume,without influence of temperature.◆Reading by IR measuring cylinder,drove by step motor,high precision screw ball.
◆Low noise air compressor refrigeration system.
◆Automatic stop after test finish.
◆Automatic temperature volume correction.
◆Automatic Atmospheric pressure compensation
◆When measuring benzene products,the electrical furnace can stop heating automatically,to prevent temperature overshoot(please inform before purchasing)
Technical Specifications
| Model |
DA-R4 Fully Automatic Distillation Apparatus |
| Applicable standards |
GB/T6536；ASTM D 86,ISO 3405； |
| Measuring temperature |
Ambient~+400℃ |
| Temperature controlling accuracy |
+/- 0.1℃ |
| Volume accuracy |
+/- 0.1 ml |
| Temperature of measuring cylinder |
0～60℃ |
| Distillation rate |
4～5ml/min |
| Heating mode |
Feedback heater |
| Display mode |
10.4 inch LCD screen |
| Refrigeration mode |
Air compressor |
| Heating power |
2500W |
| Dimension |
600*450*650mm |
| Net weight |
53KG |
