| Lugar de origen: | PORCELANA |
| Nombre de la marca: | AI |
| Certificación: | ISO |
| Número de modelo: | AIC2571 |
| Cantidad de orden mínima: | 1 unidad |
|---|---|
| Precio: | Negociable |
| Detalles de empaquetado: | Caja de cartón |
| Tiempo de entrega: | 15 días |
| Condiciones de pago: | T/T, Western Union, L/C |
| Capacidad de la fuente: | 100000 conjuntos por mes |
| Rango de medición: | 0-1,999 Ω, 2-19,99 Ω, 20-199,9 Ω | Mostrar: | Digital |
|---|---|---|---|
| palabra clave: | Probador de resistencia a tierra, medidor de resistencia a tierra | Peso: | 2 kg |
| Garantía: | 1 año | Color: | Blanco |
![]()
1 Application
This earthing resistance tester is suitable to test earth resistance of all kinds of devices and Conductor resistance of low resistance in electric power, post,oil,chemistry,communication,mine industry and so on..It also can test resistance rate of soil and voltage to earth.
2 Technical parameters
| Range | Constant Current Value | Precision and Error | Resolution | Additional | |
|
0-1.999Ω 2-19.99Ω 20-199.9Ω AC:0-19.99V |
10mA(2Ω) 10mA(20Ω) 1mA(200Ω) <±(10%+1d) |
0-0.2Ω<±(3%+1d) 0.2-199.9Ω <±(1.5%+1d) 1-20V<±(3%+1d) |
0.001Ω 0.01Ω 0.1Ω 0.01V |
Rc:2Ω 20Ω/<1KΩ 200Ω/<10KΩ Rp:<50KΩ Error:< ±5% |
|
| Power Consumption | Earth Voltage | Humidity | ≤85%RH | Power Supply | Weight: <1.8Kg |
| ≤2W | <5V,<±5% | Temperature | 0℃-40℃ | 7.2-9V DC or 220V AC | Size: 200×200×110mm3 |
