Introduction
Using method: cool the sample under certain condition,and pass sample throughafilter with 363 mesh.When the sample is cooled to required temperature,reduce temperature in every 1℃ interval,and measure the temperature while filter is being blocked.
Characteristics
1.This Cold Filter Plugging Point Apparatus adopts enclosed refrigeration,environment-friendly refrigerant,speedy cooling.
2.Imported self-priming pump circulation from Taiwan guarantees excellent temperature evenness.
3.Integrated structure is easy to move.
4.The CFPP Tester made by cold-rolled sheet,surface treated by Electrostatic spraying.It’s corrosion resisting and easy to clean.
5.The Cold filter plugging point apparatus adopts butt welding technology,so there isn’t welding spot on the surface.It’s beautiful and clean.
6.Micro-computer controller,PID function,digitally display temperature(continuously display during test),accuracy 0.1℃,Pt100 temperature sensor.
Technical specifications
| 1 |
Applicable standard |
SH/T0248 ASTM D6371 IP306 |
| 2 |
Power supply |
AC220±10% 50Hz±5% |
| 3 |
Temperature controlling method |
imported PID digital display temperature controller |
| 4 |
Temperature controlling accuracy |
-70±0.1℃ |
| 5 |
Refrigeration method |
imported double compressor |
| 6 |
Timing method |
digital timer |
| 7 |
Total power |
1500W |
| 8 |
Working unit |
2 holes |
Photo of ASTM D6371 Cold Filter Plugging Point Apparatus CFPP Tester
