Protective Clothing Vertical Flame Spread Tester ISO 6941,ISO 15025,95/28/EC

Datos del producto:

Lugar de origen:	PORCELANA
Nombre de la marca:	AI
Certificación:	ISO
Número de modelo:	VFT

Pago y Envío Términos:

Cantidad de orden mínima:	1 set
Precio:	Negociable
Detalles de empaquetado:	Caja de madera contrachapada
Tiempo de entrega:	60 días
Condiciones de pago:	Unión occidental, T/T, L/C
Capacidad de la fuente:	20 juegos por mes

Contactar ahora

Descripción detallada del producto

Estándar de prueba:	ISO 6941,ISO 15025,95/28/CE	Tamaño:	410m m (W) X 900m m (H) X 380m m (D)
Peso:	36 kg	Garantía:	1 año
Suministros de gas:	Aire comprimido del propano y del aire	Fuente de alimentación:	230 voltios CA 50 Hz

Protective Clothing Vertical Flame Spread Tester

Name: Protective Clothing Vertical Flame Spread Tester ISO 6941,ISO 15025,95/28/EC
Brand: Advanced Instruments Co.,Ltd
SKU: VFT
Availability: InStock

INTRODUCTION

Vertical Flame Tester is suitable for the measurement of limited flame spread properties of Protective clothing.. A defined flame from a specified burner is applied for 10 s to the surface or the bottom edge of textile specimens which are vertically oriented.

FEATURE

The vertical flame test apparatus is designed and manufactured according to ISO 15025 standards.
The flame spread tester can be updated to meet the requirement of ISO6941,ISO 6940 etc by using different specimen holders.
The apparatus consists of mounting frame, gas burner, test specimen holder with Supporting pins.
The angle of the burner can be pre-setted and adjusted automatically.
Flame application time can be pre-setted and operate automatically.
Afterflame time and afterglow time recorded by LCD screen.

Installation requirements

Electrical	230 Volts AC 50Hz.
Ambient Temperature	Operating 25±5℃
Dimensions	4410mm(W) X 900mm(H) X 380mm(D)
Weight	36KG
Applicable standards	ASTM D2863,ISO 4589-2,NES 714
Gas	Propane and air compressed air
